Part Number: 60CKQ045



MFG: IR

Package Cooled: TO-258AA

D/C: 05+

Description: The 60CKQ045 center tap Schottky rectifier has been expressly designed to meet the rigorous requiremen...


Urgent Purchase

60CKQ045 General Description


The 60CKQ045 center tap Schottky rectifier has been expressly designed to meet the rigorous requirements of hi-rel environments. It is packaged in the hermetic isolated TO-258AA package. The device's forward voltage drop and reverse leakage current are optimized for the lowest power loss and the highest circuit efficiency for typical high frequency switching power supplies and resonent power converters. Full MIL-PRF-19500 quality conformance testing is available on source controlled drawings to TX, TXV and S levels.

60CKQ045 Maximum Ratings

Characteristics Values Units
IF(AV) Rectangular
waveform		 45 A
VRRM (Per Leg) 45 V
IFSM @ tp = 8.3ms half-sine
(Per Leg)
 400 A
V F 25 Apk, T = 125°C 0.62 V
TJ, Tstg Operating and storage - 50 to150 °C

60CKQ045 Features

• Hermetically Sealed
• Center Tap
• Low Forward Voltage Drop
• High Frequency Operation
• Guard Ring for Enhanced Ruggedness and Long Term Reliability
• Electrically Isolated

60CKQ045 datasheet

60CKQ045
PDF/DataSheet Download

Find 60CKQ045 Suppliers

  • ·60CDQ
  • IRF [International Rectifier]
  • 40 AND 60 AMP DUAL SCHOTTKY CENTER TAP RECTIFIERS
  • 252487 KB
  • 60CDQ Datasheet Download
  • ·60CDQ... SERIES
  •
  • SCHOTTKY RECTIFIER 60 Amp
  • 54803 KB
  • 60CDQ... SERIES Datasheet Download
  • ·60CDQ20
  • IRF [International Rectifier]
  • 40 AND 60 AMP DUAL SCHOTTKY CENTER TAP RECTIFIERS
  • 252487 KB
  • 60CDQ20 Datasheet Download
  • ·60CDQ30
  • IRF [International Rectifier]
  • 40 AND 60 AMP DUAL SCHOTTKY CENTER TAP RECTIFIERS
  • 252487 KB
  • 60CDQ30 Datasheet Download
  • ·60CDQ35
  • IRF [International Rectifier]
  • 40 AND 60 AMP DUAL SCHOTTKY CENTER TAP RECTIFIERS
  • 252487 KB
  • 60CDQ35 Datasheet Download
  • ·60CDQ40
  • IRF [International Rectifier]
  • 40 AND 60 AMP DUAL SCHOTTKY CENTER TAP RECTIFIERS
  • 252487 KB
  • 60CDQ40 Datasheet Download
  • ·60CDQ45
  • IRF [International Rectifier]
  • 40 AND 60 AMP DUAL SCHOTTKY CENTER TAP RECTIFIERS
  • 252487 KB
  • 60CDQ45 Datasheet Download
  • ·60CIQ045
  • IRF [International Rectifier]
  • SCHOTTKY RECTIFIER
  • 352167 KB
  • 60CIQ045 Datasheet Download

Related Part Number

60CKQ045 Relative Products

  • 60CJ

    60CJ

    FUSE 60A 600V CERAM BODY CSA

  • 60CIQ045

    60CIQ045

    The 60CIQ045 center tap Schottky rectifier has been expressly designed to meet the rigorous requirements of hi-rel environments. It is packaged in the hermetic isolated TO-259AA package. The 60CIQ045's forward voltage drop and reverse leakage current are opt...

  • 60CIK07

    60CIK07

    FUSE 60A 600V CERAM BODY CSA

  • 60CDQ...

    60CDQ...

    The 60CDQ... center tap Schottky rectifier series has been optimized for low reverse leakage at high temperature. The proprietary barrier technology allows for reliable operation up to 175° C junction temperature. Typical applications of 60CDQ... are in swit...

  • 60C22-M7-4-040C
