Product Details

Description



Features:

- Output current in excess of 0.5A
- No external components
- Internal thermal overload protection
- Internal short circuit current-limiting
- Output transistor safe-area compensation



Specifications

DC Input Voltage                                          35V
Internal Power Dissipation
(Note 2)
                                                                     Internally Limited
Maximum Junction Temperature
                                                                     150 C
Storage Temperature Range
                                                                      -65 C to +150 C
Lead Temperature
       Soldering, (10 seconds)                          300 C
Thermal Resistance
     ThetaJA
         (Still Air)                                                 232 C/W
         (500 LF/Min Air Flow)                             77 C/W
         ThetaJC                                                 15 C/W
ESD Susceptibility
(Note 3)
                                                                       2KV
Note 1: Absolute Maximum Ratings are limits beyond which damage to the device may occur.Operating Conditions are conditions under which the device functions but the specification might not be guaranteed. For guaranteed specifications and test conditions see the Electrical Characteristics.

Note 2: The Maximum allowable power dissipation at any ambient temperature is a function of the maximum junction temperature for operation (TjMAX = 150 C), the junction-to-ambient thermal resistance (ThetaJA), and the ambient temperature (TA).PDMAX = (TjMAX - TA)/ThetaJA. If this dissipation is exceeded, the die temperature will rise above TjMAX and the electrical specifications do not apply. If the die temperature rises above 150 C, the device will go into the thermal shutdown.

Note 3: Human body model, 100pF discharged through 1.5K Ohms




Description

The LM140 monolithic 3-terminal positive voltage regulators employ internal current limiting, thermal shutdown and safe-area compensation, making them essentially indestructible. If adequate heat sinking is provided, they can deliver over 0.5A output current. LM140 are intended as fixed voltage regulators in a wide range of applications including local (on-card) regulation for elimination of noise and distribution problems associated with single-point regulation. In addition to use as fixed voltage regulators,these LM140 can be used with external components to obtain adjustable output voltages and currents.

Considerable effort was expended to make the entire series of regulators easy to use and minimize the number of external components. LM140 is not necessary to bypass the output,although this does improve transient response. Input bypassing is needed only if the regulator is located far from the filter capacitor of the power supply.
