Reverse Current
                                                       30mA
Forward Current
                                                       10mA
Operating Temperature Range
                                                       -55 C to +125 C
Maximum Junction Temperature
                                                       150 C
Storage Temperature
                                                       -55 C to +150 C
Lead Temperature
 (Soldering, 10 seconds)                 300 C
Thermal Resistance
ThetaJA
  H-Pkg     (Still Air)                          300 C/W
            (500LF/Min Air Flow)            139 C/W
  E-Pkg     (Still Air)                           100 C/W
            (500LF/Min Air Flow)             73 C/W
ThetaJC
   H-Pkg                                             57 C/W
   E-Pkg                                             25 C/W
Package Weight
(Typcial)
Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur.Operating Ratings indicate conditions for which the device is functional, but do not guarantee specific performance limits.  For guaranteed specifications and test conditions, see the Electrical Characteristics.  The guaranteed specifications apply only for the test conditions listed. Some performance characteristics may degrade when the device is not operated under the listed test conditions.

The 6380 is a micropower 2-terminal band-gap voltage regulator diode. Operating over a 10 uA to 20 mA current range, it features exceptionally low dynamic impedance and good temperature stability.  On-chip trimming is used to provide tight voltage tolerance. Since the LM185-1.2 band-gap reference uses only transistors and resistors, low noise and good long term stability result.

Careful design of the 6380 has made the device exceptionally tolerant of capacitive loading, making it easy to use in almost any reference application.  The wide dynamic operating range allows its use with widely varying supplies with excellent regulation. The extremely low power drain of the 6380 makes it useful for micropower circuitry. This voltage reference can be used to make portable meters, regulators or general purpose analog circuitry with battery life approaching shelf life.  Further, the wide operating current allows it to replace older references with a tighter tolerance part.
