6455

Storage Temperature Range
                                                                           -65 C to +150 C
Operating Temperature Range
                                                                           -55 C to +125 C
Maximum Junction Temperature
                                                                           150 C
Lead Temperature
Ceramic DIP (Soldering, 60 seconds)                  300 C
Internal Power Dissipation
(Note 2)
8L-Metal Can                                                       1.00W
8L-Ceramic DIP                                                    1.30W
Positive Supply Voltage
                                                                            +8.0V
Negative Supply Voltage
                                                                            -8.0V
Peak Output Current
                                                                            10mA
Differential Input Voltage
                                                                            ±5.0V
Input Voltage
                                                                            V+ VI VThermal
Resistance
ThetaJA
(Still Air)                                                               110 C/W
(500LF/Min Air flow)                                             TBD
ThetaJC                                                                TBD
ESD Susceptibility
                                                                            TBD
Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur.Operating Ratings indicate conditions for which the device is functional, but do not guarantee specific perofrmance limits. For guaranteed specifications and test conditions, see the Electrical Characteristics. The guaranteed specifications apply only for the test conditions listed. Some performance characteristics may degrade when the device is not operated under the listed test conditions.

Note 2: Ratings apply to ambient temperature at 25 C.

The 6455 is a differential voltage comparator offering considerable speed improvement over the 6455  family and operates from symmetric supplies of +4.5V to +6.5V. The 6455  can be used in high speed analog-to-digital conversion systems and as a zero crossing detector in disc file and tape amplifiers. The 6455 output features balanced rise and fall times for minimum skew and close matching between the complementary outputs. The outputs are TTL compatible with a minimum sink capability of two gate loads
