Purchase 74ALS6521, In-stock 74ALS6521 From SeekIC.
Part Number: 74ALS6521
Description: The 74LAS651 and 74ALS652 transceivers/registers consist of bustransceiver circuits with 3-State outpu...
- Table of contents:
74ALS6521
-
Suppliers
DataSheet
General Description
74ALS6521 General Description
The 74LAS651 and 74ALS652 transceivers/registers consist of bustransceiver circuits with 3-State outputs, D-typeflip-flops, andcontrol circuitry arranged for multiplexed transmission of datadirectly from the input bus or the internalregisters. Data on the A orB bus will be clocked into the registers as the appropriate clock pingoes High. Output enable (OEAB, OEBA) and select (SAB, SBA)pins are provided for bus management. The 74LAS651-1 and74ALS652-1 will sink 48mA if the VCC is limited to 5.0V ± 0.25V.
74ALS6521 Features
• Independent registers for A and B buses
• Multiplexed real-time and stored data
• Choice of non-inverting and inverting data paths
• 3-State outputs
• The -1 versions sinks 48mA IOLwithin the ±5% VCC range
• Multiplexed real-time and stored data
• Choice of non-inverting and inverting data paths
• 3-State outputs
• The -1 versions sinks 48mA IOLwithin the ±5% VCC range
74ALS6521 Connection Diagram
