74HC273DB,118

Number of Circuits : 1
Maximum Operating Temperature : + 125 C
Mounting Style : SMD/SMT
Packaging : Reel
Polarity : Non-Inverting
Input Type : Single-Ended
Output Type : Single-Ended
Supply Voltage - Max : 6 V
Logic Family : HC
High Level Output Current : - 5.2 mA
Low Level Output Current : 5.2 mA
Logic Type : D-Type Edge Triggered Flip-Flop
Package / Case : SOT-339
Propagation Delay Time : 15 ns at 5 V


Parameters:

Technical/Catalog Information	74HC273DB,118
Vendor	NXP Semiconductors
Category	Integrated Circuits (ICs)
Mounting Type	Surface Mount
Package / Case	20-SSOP
Function	Master Reset
Number of Bits per Element	8
Number of Elements	1 - Single
Current - Output High, Low	5.2mA, 5.2mA
Output Type	Non-Inverted
Trigger Type	Positive Edge
Type	D-Type Bus
Packaging	Tape & Reel (TR)
Operating Temperature	-40°C ~ 125°C
Delay Time - Propagation	13ns
Frequency - Clock	122MHz
Voltage - Supply	2 V ~ 6 V
Drawing Number	568; SOT339; ;
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	74HC273DB,118 74HC273DB,118
