74LCX08 Product Image

74L Series Datasheet download

Five Points

Part Number: 74LCX08



MFG: F

Package Cooled: tssop14



Description: The LCX08 contains four 2-input AND gates. The inputs tolerate voltages up to 7V allowing the interface of...


Urgent Purchase

74LCX08 General Description


   The LCX08 contains four 2-input AND gates. The inputs tolerate voltages up to 7V allowing the interface of 5V systems to 3V systems.

   The 74LVX08 is fabricated with advanced CMOS technology to achieve high speed operation while maintaining CMOS low power dissipation.

74LCX08 Maximum Ratings

Symbol Parameter Value Conditions Units
VCC Supply Voltage −0.5 to +7.0 V
VI DC Input Voltage −0.5 to +7.0 V
VO DC Output Voltage −0.5 to VCC +0.5 Output in HIGH or LOW State (Note4) V
IIK DC Input Diode Current −50 VI < GND mA
IOK DC Output Diode Current −50
+50 		VO < GND
VO > VCC		 mA
IO DC Output Source/Sink Current ±50 mA
ICC DC Supply Current per Supply Pin ±100 mA
IGND DC Ground Current per Ground Pin ±100 mA
TSTG Storage Temperature −65 to +150 °C

74LCX08 Features

 5V tolerant inputs
  2.3V3.6V VCC specifications provided
  5.5 ns tPD max (VCC   3.3V), 10 A ICC max
  Power down high impedance inputs and outputs
  ±24 mA output drive (VCC   3.0V)
  Implements patented noise/EMI reduction circuitry
  Latch-up performance exceeds JEDEC 78 conditions
  ESD performance:
   Human body model ! 2000V
   Machine model ! 150V
  Leadless Pb-Free DQFN package

74LCX08 Connection Diagram

74LCX08 Connection Diagram
