74LS138

The LSTTL/MSI 74LS138 is a high speed 1-of-8 Decoder/ Demultiplexer. This device is ideally suited for high speed bipolar memory chip select address decoding. The multiple input enables allow parallel expansion to a 1-of-24 decoder using just three LS138 devices or to a 1-of-32 decoder using four LS138s and one inverter. The 74LS138 is fabricated with the Schottky barrier diode process for high speed and is completely compatible with all Motorola TTL families.
