Description: The SN54/74LS173A is a high-speed 4-Bit Register featuring 3-state outputs for use in bus-organized sy...
- Table of contents:
74LS173A
-
Suppliers
DataSheet
General Description
74LS173A General Description
The SN54/74LS173A is a high-speed 4-Bit Register featuring 3-state outputs for use in bus-organized systems. The clock is fully edge-triggered allowing either a load from the D inputs or a hold (retain register contents) depending on the state of the Input Enable Lines (IE1, IE2). A HIGH on either Output Enable line (OE1, OE2) brings the output to a high impedance state without affecting the actual register contents. A HIGH on the Master Reset (MR) input resets the Register regardless of the state of the Clock (CP), the Output Enable (OE1, OE2) or the Input Enable (IE1, IE2) lines.
74LS173A Features
• Fully Edge-Triggered
• 3-State Outputs
• Gated Input and Output Enables
• Input Clamp Diodes Limit High-Speed Termination Effects
• 3-State Outputs
• Gated Input and Output Enables
• Input Clamp Diodes Limit High-Speed Termination Effects
74LS173A Connection Diagram
74L71
PDF/DataSheet Download
- Datasheet: 74L71
- File Size: 105703 KB
- Manufacturer: TI [Texas Instruments]
- Click here to Download
