74LS175

The LSTTL/MSI 74LS175 is a high speed Quad D Flip-Flop. The device is useful for general flip-flop requirements where clock and clear inputs are common. The information on the D inputs is stored during the LOW to HIGH clock transition. Both true and complemented outputs of each flip-flop are provided. A Master Reset input resets all flip-flops, independent of the Clock or D inputs, when LOW.

The 74LS175 is fabricated with the Schottky barrier diode process for high speed and is completely compatible with all Motorola TTL families.
