Purchase 7542, In-stock 7542 From SeekIC.
MFG:N/A Package Cooled:DIP
Part Number: 7542
MFG: N/A
Package Cooled: DIP
Description: The 7542 Group is the 8-bit microcomputer based on the 740 family core technology.The 7542 Gro...
- Table of contents:
7542
-
Suppliers
DataSheet
General Description
7542 General Description
The 7542 Group is the 8-bit microcomputer based on the 740 family core technology.
The 7542 Group has serial interfaces, 8-bit timers, 16-bit timers, and an A/D converter, and is useful for control of home electric appliances and office automation equipment.
7542 Maximum Ratings
| Symbol | Parameter | Conditions | Ratings | Unit |
| VCC | Power source voltage | All voltages are based on Vss. Output transistors are cut off. |
0.3 to 6.5 | V |
| VI | Input voltage P00P07, P10P14, P20P27,P30P37, VREF | 0.3 to VCC+0.3 | V | |
| VI | Input voltage RESET, XIN | 0.3 to VCC+0.3 | V | |
| VI | Input voltage CNVSS | 0.3 to VCC+0.3 | V | |
| VO | Output voltage P00P07, P10P14, P20P27, P30P37, XOUT |
0.3 to VCC+0.3 | V | |
| Pd | Power dissipation | Ta = 25 | 300(Note) | mW |
| Topr | Operating temperature | 20 to 85 | ||
| Tstg | Storage temperature | 40 to 125 |
7542 Features
• Basic machine-language instructions ...................................... 71
• The minimum instruction execution time ............................. 0.25 s
(at 8 MHz oscillation frequency, double-speed mode for the shortest instruction)
• Memory size
Flash memory version: ROM ..................... 16 to 32K + 4K bytes
RAM ..................................... 1024 bytes
Mask ROM version: ROM............................. 8K to 16K bytes
RAM ............................ 384 to 512 bytes
RSS version RAM ..................................... 1024 bytes
• Programmable I/O ports
29 (25 in 32-pin version and PWQN0036KA-A package version)
• Interrupts ................................................. 18 sources, 16 vectors
• Timers ............................................................................. 8-bit ✕ 2
...................................................................................... 16-bit ✕ 2
• Output compare ............................................................ 4-channel
• Input capture ................................................................ 2-channel
• Serial interface ............ 8-bit ✕ 2 (UART or Clock-synchronized)
• A/D converter ............................................... 10-bit ✕ 8 channels
(6 channels in 32-pin version and PWQN0036KA-A package version)
• Clock generating circuit ............................................. Built-in type
(low-power dissipation by an on-chip oscillator)
(connected to external ceramic resonator or quartz-crystal
oscillator permitting RC oscillation)
• Watchdog timer ............................................................ 16-bit ✕ 1
• Power source voltage
XIN oscillation frequency at ceramic oscillation, in double-speed mode
At 8 MHz .................................................................... 4.5 to 5.5 V
XIN oscillation frequency at ceramic oscillation, in high-speed mode
At 8 MHz .................................................................... 4.0 to 5.5 V
At 4 MHz .................................................................... 2.4 to 5.5 V
At 2 MHz .................................................................... 2.2 to 5.5 V
XIN oscillation frequency at RC oscillation in high-speed mode or middle-speed mode
At 4 MHz .................................................................... 4.0 to 5.5 V
At 2 MHz .................................................................... 2.4 to 5.5 V
At 1 MHz .................................................................... 2.2 to 5.5 V
• Power dissipation ................................................ 27.5 mW (Typ.)
• Operating temperature range ................................... 20 to 85
• The minimum instruction execution time ............................. 0.25 s
(at 8 MHz oscillation frequency, double-speed mode for the shortest instruction)
• Memory size
Flash memory version: ROM ..................... 16 to 32K + 4K bytes
RAM ..................................... 1024 bytes
Mask ROM version: ROM............................. 8K to 16K bytes
RAM ............................ 384 to 512 bytes
RSS version RAM ..................................... 1024 bytes
• Programmable I/O ports
29 (25 in 32-pin version and PWQN0036KA-A package version)
• Interrupts ................................................. 18 sources, 16 vectors
• Timers ............................................................................. 8-bit ✕ 2
...................................................................................... 16-bit ✕ 2
• Output compare ............................................................ 4-channel
• Input capture ................................................................ 2-channel
• Serial interface ............ 8-bit ✕ 2 (UART or Clock-synchronized)
• A/D converter ............................................... 10-bit ✕ 8 channels
(6 channels in 32-pin version and PWQN0036KA-A package version)
• Clock generating circuit ............................................. Built-in type
(low-power dissipation by an on-chip oscillator)
(connected to external ceramic resonator or quartz-crystal
oscillator permitting RC oscillation)
• Watchdog timer ............................................................ 16-bit ✕ 1
• Power source voltage
XIN oscillation frequency at ceramic oscillation, in double-speed mode
At 8 MHz .................................................................... 4.5 to 5.5 V
XIN oscillation frequency at ceramic oscillation, in high-speed mode
At 8 MHz .................................................................... 4.0 to 5.5 V
At 4 MHz .................................................................... 2.4 to 5.5 V
At 2 MHz .................................................................... 2.2 to 5.5 V
XIN oscillation frequency at RC oscillation in high-speed mode or middle-speed mode
At 4 MHz .................................................................... 4.0 to 5.5 V
At 2 MHz .................................................................... 2.4 to 5.5 V
At 1 MHz .................................................................... 2.2 to 5.5 V
• Power dissipation ................................................ 27.5 mW (Typ.)
• Operating temperature range ................................... 20 to 85
7542 Typical Application
·Office automation equipment, factory automation equipment, home electric appliances, consumer electronics, etc.
7542 Connection Diagram
