79L00A

Features: · High Output Current IO= 100 mA· Fixed Output Voltage VO= -5 V, -6 V, -8 V, -12 V, -15 V· Complementary Positive Regulators 78L00A Series· Available in either ±5% (AC) SelectionSpecifications Rating Symbol Value Unit Input VoltageVO = -5 V to -9 VVO = -12 V to -15 V ...

product image

79L00A Picture
See larger image
SeekIC No. : 004252871 Detail

79L00A: Features: · High Output Current IO= 100 mA· Fixed Output Voltage VO= -5 V, -6 V, -8 V, -12 V, -15 V· Complementary Positive Regulators 78L00A Series· Available in either ±5% (AC) SelectionSpecificat...

79L00A Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
79L00A
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·  High Output Current IO= 100 mA
·  Fixed Output Voltage VO= -5 V, -6 V, -8 V, -12 V, -15 V
·  Complementary Positive Regulators 78L00A Series
·  Available in either ±5% (AC) Selection


Specifications

Rating
Symbol
Value
Unit
Input Voltage
VO = -5 V to -9 V
VO = -12 V to -15 V
VI
-30
-35
V

Output Current
IO
100
mA
Maximum Power Dissipation
Case KT-26 (TO-92) Z Suffix
Case KT-47 (SOT-89) F Suffix
Case 4303.8-1 (SO-8) D Suffix
PD
500
350
500
mW

Junction Temperature
Operating Junction Temperature Range
Storage Temperature Range
TJMAX
TOPR
TSTG
150
-30 to +85
-40 to +150
°C
°C
°C



Description

The 79L00A Series of three terminal negative voltage regulators is available with several fixed output voltages making them useful in a wide range of applications. These regulators are inexpensive, vise-to-use devices suitable for a multitude of applications that require a regulated supply of up to 100 mA. These regulators feature internal current limiting and thermal shutdown of the 79L00A making them remarkably rugged. No external components are required with the 79L00A devices in many applications.

These devices offer a substantial performance advantage over the traditional zener diode-resistor combination, as output impedance and quiescent current are substantionally reduced. The voltages available allow the 79L00A to be used in logic systems, instrumentation, HiFi, and other solid state electronic equipment.

The 79L00A is available in 3-Pin plastic package SOT54 (Z), 3-Pin mini power plastic package SOT89 (F) and the 8-Pin plastic package SO8 (D) offers superior quality and performance at low cost.
