Purchase 88CNQ060A, In-stock 88CNQ060A From SeekIC.
Part Number: 88CNQ060A
Description: The 88CNQ060A center tap Schottky rectifier module has been optimized for very low forward voltage dr...
- Table of contents:
88CNQ060A
-
Suppliers
DataSheet
General Description
88CNQ060A General Description
The 88CNQ060A center tap Schottky rectifier module has been optimized for very low forward voltage drop, with moderate leakage. The proprietary barrier technology allows or reliable operation up to 150°C junction temperature. Typical applications are in switching power supplies, converters, free wheeling diodes, and reverse battery protection.
88CNQ060A Maximum Ratings
| Parameters | 80CNQ | Units | Conditions | |
| I F(AV)Max. Average Forward (Per Leg)Current * See Fig. 5 (Per Device) | 40 | A | 50% duty cycle @ TC = 120 .rectangular wave form | |
| 80 | ||||
| I FSMMax. Peak One Cycle Non-RepetitiveSurge Current (Per Leg) * See Fig. 7 | 5000 | A | 5s Sine or 3s Rect. pulse | Following any rated load condition and wit rated VRRM applied |
| 600 | 10ms Sine or 6ms Rect. pulse | |||
| EASNon-Repetitive Avalanche Energ(Per Leg) | 75 | MJ | TJ = 25 , I AS= 1 Amps, L = 0.57 mH | |
| I ARRepetitive Avalanche Current (Per Leg) |
1.0 | A | Current decaying linearly to zero in 1 sec Frequency limited by TJ max. V A = 1.5 x VR typical | |
88CNQ060A Features
150 Tj operation
Center tap module
High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance
Low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term reliability
New fully transfer-mold low profile, small footprint, high current package
Center tap module
High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance
Low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term reliability
New fully transfer-mold low profile, small footprint, high current package
