See larger image

SeekIC No. : 001211834 Detail

9250A-474-RC: RF Inductors 470uH 10%

9250A-474-RC Data Sheet

US $ .38~1.1 / Piece | Get Latest Price

Part Number:: 9250A-474-RC
Mfg:: Bourns
Supply Ability:: 5000

Price Break

Qty
0~1
1~50
50~100
100~500

Unit Price
$1.1
$.55
$.48
$.38

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

9250-101 evaluate
RF Inductors 0.10uH 10%
9250-101-RC evaluate
RF Inductors 0.10uH 10%
9250-102 evaluate
RF Inductors 1.0uH 10%

Product Details

Quick Details

Inductance :	470 uH	Tolerance :	10 %
Maximum DC Current :	92 mAmps	Maximum DC Resistance :	9.5 Ohms
Self Resonant Frequency :	5.7 MHz	Q Minimum :	60
Operating Temperature Range :	- 55 C to + 125 C	Termination Style :	Axial

Description

Package / Case :
Operating Temperature Range : - 55 C to + 125 C
Tolerance : 10 %
Q Minimum : 60
Termination Style : Axial
Inductance : 470 uH
Self Resonant Frequency : 5.7 MHz
Maximum DC Current : 92 mAmps
Maximum DC Resistance : 9.5 Ohms

Parameters:

Technical/Catalog Information	9250A-474-RC
Vendor	JW Miller A Bourns Company
Category	Inductors, Coils, Chokes
Inductance	470H
Tolerance	±10%
Package / Case	Axial
Packaging	Bulk
Type	Ferrite Core
Current	92mA
Mounting Type	Through Hole
Q @ Freq	60 @ 790kHz
Self Resonant Freq	5.7MHz
DC Resistance (DCR)	9.500 Ohm Max
Shielding	Shielded
Applications	EMI Filter
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	9250A 474 RC 9250A474RC M10120 ND M10120ND M10120
