Purchase A05D12, In-stock A05D12 From SeekIC.
Part Number: A05D12
Description: The A and F Series offer high input/output isolation of 500VDC with only 1mV rms (40mV pk-pk) output ripple and noise.&...
- Table of contents:
A05D12
-
Suppliers
DataSheet
General Description
A05D12 General Description
The A and F Series offer high input/output isolation of 500VDC with only 1mV rms (40mV pk-pk) output ripple and noise. Other premium performance features include line and load regulation of less than ±0.1% and efficiencies of up to 69%. The converters are encapsulated in a 2 x 2 inch industry standard package with a 0.38 inch profile. The six sided copper case allows optimum thermal conductivity and provides shielding for EMI/RFI suppression. A Pi input filter reduces reflected ripple. Reliable operation is assured through the use of efficient, design-derated components and by heatsinking all dissipating elements directly to the metal case. This permits operation from -25 to +71 with no derating or additional heatsinking required. A and F Series DC/DC converter are suitable for a wide range of general industrial applications, especially where low noise levels are required.
A05D12 Features
• Low noise
• Linear regulation
• Six sided shield
• Pi input filter
• Short circuit protected
• High Isolation
• Meets EN55022 and VDE0871 level B conducted noise
• Linear regulation
• Six sided shield
• Pi input filter
• Short circuit protected
• High Isolation
• Meets EN55022 and VDE0871 level B conducted noise
A05D12
PDF/DataSheet Download
- Datasheet: A05D12
- File Size: 38158 KB
- Manufacturer: ETC [ETC]
- Click here to Download
