Features: • Less than 0.4ps RMS (12kHz-20MHz) phase jitter for all frequencies.• Less than 25ps peak to peak jitter for all frequencies.• Low phase noise output (@ 1MHz frequency offset-144dBc/Hz for 106.25MHz-144dBc/Hz for 156.25MHz-144dBc/Hz for 212.5MHz-140dBc/Hz for 312.5MHz,...
ABX8037: Features: • Less than 0.4ps RMS (12kHz-20MHz) phase jitter for all frequencies.• Less than 25ps peak to peak jitter for all frequencies.• Low phase noise output (@ 1MHz frequency o...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
PARAMETERS | SYMBOL | MIN. | MAX. | UNITS |
Supply Voltage | VDD | 4.6 | V | |
Input Voltage, dc | VI | -0.5 | VDD+0.5 | V |
Output Voltage, dc | VO | -0.5 | VDD+0.5 | V |
Storage Temperature | TS | -65 | 150 | °C |
Ambient Operating Temperature* | TA | -40 | 85 | °C |
Junction Temperature | TJ | 125 | °C | |
Lead Temperature (soldering, 10s) | 260 | °C | ||
ESD Protection, Human Body Model | 2 | kV |
The ABX803X is a monolithic low jitter and low phase noise high performance clock, capable of maintaining 0.4ps RMS phase jitter and CMOS, LVDS or PECL outputs, covering a wide frequency output range up to 640MHz. It allows high performance and high frequency output, using a low cost fundamental crystal of between 19-40MHz.
The frequency selector pads of ABX803X enable output frequencies of (2, 4, 8, or 16) * FXIN. The ABX803X is designed to address the demanding requirements of high performance applications such Fiber Channel, serial ATA, Ethernet, SAN, etc.
