Features: Isolated plastic package (modified TO-220AB) 150 A surge current ApplicationMotor speed control Lamp dimmer, temperature controllers Various solid state switches, etc. Specifications Parameter Symbol AC16DSMA AC16FSMA Unit Remarks Non-repetitive Peak Off-state Voltage ...
AC16FSMA: Features: Isolated plastic package (modified TO-220AB) 150 A surge current ApplicationMotor speed control Lamp dimmer, temperature controllers Various solid state switches, etc. Specifications ...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Parameter | Symbol | AC16DSMA | AC16FSMA | Unit | Remarks |
Non-repetitive Peak Off-state Voltage | VDSM | 500 | 700 | V | - |
Repetitive Peak Off-state Voltage | VDRM | 400 | 600 | V | - |
Effective On-state Current | IT(RMS) | 16(TC=68) | A | Refer to Figure 11 and 12. | |
Surge On-state Current | ITSM | 150 (50 Hz 1 cycle) 160 (60 Hz 1 cycle) |
A | Refer to Figure 2. | |
Fusing Current | it 2dt | 5 (1 ms t 10 ms) | A 2S | - | |
Critical Rate Rise of On-state Current | dit/dt | 50 | A/s | - | |
Peak Gate Power Dissipation | PGM | 5.0 (f 50 Hz, Duty 10%) | W | Refer to Figure 3. | |
Average Gate Power Dissipation | pg(av) | 0.5 | w | ||
Peak Gate Current | IGM | ±3 (f 50 Hz, Duty 10%) | a | ||
Junction Temperature | Ti | -40~+125 | °C | - | |
Storage Temperature Tstg | Tstg | -55~+150 | °C | - |
The AC16DSMA and AC16FSMA are all diffused mold type triac granted RMS on-state current 16 A, with rated voltages up to 600 V.
