MFG:ANDAIGIC Package Cooled:SOP16
MFG: ANDAIGIC
Package Cooled: SOP16
Description: The ACA2407 is a highly linear, monolithic GaAs RF amplifier that has been developed to replace, in ne...
The ACA2407 is a highly linear, monolithic GaAs RF amplifier that has been developed to replace, in new designs, standard CATV hybrid amplifiers. Offered in a convenient surface mount package, the MMIC consists of two pairs of parallel amplifiers that are optimized for exceptionally low distortion and noise figure. A hybrid equivalent that provides flat gain response and excellent input and output return loss over the 40 to 870 MHz CATV downstream band is formed when one ACA2407 is cascaded between two appropriate transmission line baluns.
| PARAMETER | MIN | MAX | UNIT |
| Supply(pins 12, 13) | 0 | +28 | CVD |
| Current Adjust (pin6) | 0 | +4 | CVD |
| RF Power at Inputs (pins 4, 5) | - | +75 | VdBm |
| S5torage Temperature | -65 | +150 | C |
| Soldering Temperature | - | +260 | C |
| Soldering Time | - | 5.0 | cse |
21.5 dB Gain
Very Low Distortion
Excellent 75 ? Input and Output Match
Stable with High VSWR Load Conditions
Monolithic Design for Consistent Performance Part-to-Part
Low DC Power Consumption
Surface Mount Package Compatible with Automatic Assembly
Low Cost Alternative to Hybrids
Meets Cenelec Standards
ACA2407
PDF/DataSheet Download
