Part Number: ACS257MS
Description: The Radiation Hardened ACS257MS is a Quad 2-Channel multiplexer which selects four bits of data from o...
- Table of contents:
ACS257MS
-
Suppliers
DataSheet
General Description
ACS257MS General Description
The Radiation Hardened ACS257MS is a Quad 2-Channel multiplexer which selects four bits of data from one of two sources under the control of a single select pin. The Output Enable input is active LOW and controls all outputs. When OE is set HIGH, all outputs are configured into a high impedance state, regardless of all other input conditions. All inputs are buffered and the outputs are designed for balanced propagation delay and transition times.
The ACS257MS is fabricated on a CMOS Silicon on Sapphire (SOS) process, which provides an immunity to Single Event
Latch-up and the capability of highly reliable performance in any radiation environment. These devices offer significant
power reduction and faster performance when compared to ALSTTL types.
ACS257MS Features
• QML Qualified Per MIL-PRF-38535 Requirements
• 1.25Micron Radiation Hardened SOS CMOS
• Radiation Environment
- Latch-up Free Under any Conditions
- Total Dose . . . . . . . . . . . . . . . . . . . . .3 x 105 RAD(Si)
- SEU Immunity . . . . . . . . . . <1 x 10-10 Errors/Bit/Day
- SEU LET Threshold . . . . . . . . . . . >100MeV/(mg/cm2)
• Input Logic Levels .VIL = (0.3)(VCC), VIH = (0.7)(VCC)
• Output Current . . . . . . . . . . . . . . . . . . . . . . . . ±8mA
• Quiescent Supply Current. . . . . . . . . . . . . . . . 400A
• Propagation Delay
- Enable to Output . . . . . . . . . . . . . . . . . . . . . . . 13ns
- Input or Address to Output . . . . . . . . . . . . . . . 14ns
• 1.25Micron Radiation Hardened SOS CMOS
• Radiation Environment
- Latch-up Free Under any Conditions
- Total Dose . . . . . . . . . . . . . . . . . . . . .3 x 105 RAD(Si)
- SEU Immunity . . . . . . . . . . <1 x 10-10 Errors/Bit/Day
- SEU LET Threshold . . . . . . . . . . . >100MeV/(mg/cm2)
• Input Logic Levels .VIL = (0.3)(VCC), VIH = (0.7)(VCC)
• Output Current . . . . . . . . . . . . . . . . . . . . . . . . ±8mA
• Quiescent Supply Current. . . . . . . . . . . . . . . . 400A
• Propagation Delay
- Enable to Output . . . . . . . . . . . . . . . . . . . . . . . 13ns
- Input or Address to Output . . . . . . . . . . . . . . . 14ns
ACS257MS Typical Application
• 4-Bit Source Selection
• Data Routing
• High Frequency Switching
• Data Routing
• High Frequency Switching
ACS257MS Connection Diagram
ACS257MS
PDF/DataSheet Download
- Datasheet: ACS257MS
- File Size: 49532 KB
- Manufacturer: INTERSIL [Intersil Corporation]
- Click here to Download
- ·ACS00D
- INTERSIL [Intersil Corporation]
- Radiation Hardened Quad 2-Input NAND Gate
- 70193 KB
- ·ACS00DMSR
- INTERSIL [Intersil Corporation]
- Radiation Hardened Quad 2-Input NAND Gate
- 70193 KB
- ·ACS00HMSR
- INTERSIL [Intersil Corporation]
- Radiation Hardened Quad 2-Input NAND Gate
- 70193 KB
- ·ACS00K
- INTERSIL [Intersil Corporation]
- Radiation Hardened Quad 2-Input NAND Gate
- 70193 KB
- ·ACS00KMSR
- INTERSIL [Intersil Corporation]
- Radiation Hardened Quad 2-Input NAND Gate
- 70193 KB
- ·ACS00MS
- INTERSIL [Intersil Corporation]
- Radiation Hardened Quad 2-Input NAND Gate
- 70193 KB
- ·ACS02D
- INTERSIL [Intersil Corporation]
- Radiation Hardened Quad 2-Input NOR Gate
- 51530 KB
- ·ACS02K
- INTERSIL [Intersil Corporation]
- Radiation Hardened Quad 2-Input NOR Gate
- 51530 KB
ACS257MS Relative Products
ACS253MS
The Radiation Hardened ACS253MS is a Dual 4-Channel Multiplexer having two common binary control inputs for selecting 1 of 4 data channels. All inputs and outputs are buffered and are designed for balanced propagation delay and transition times.Separate Outp...
ACS245MS
The Intersil ACS245MS is a Radiation Hardened octal non-inverting bidirectional bus transceiver intended for two-way asynchronous communication between data busses.The ACS245MS utilizes advanced CMOS/SOS technology to achieve high-speed operation. This devic...
ACS244MS
The Radiation Hardened ACS244MS is a Non-Inverting,Octal, Three-State Buffer/Line Driver with two active-LOW Enable inputs (AE and BE). Each Enable input controls four outputs. When an Enable input is LOW, the correspondingoutputs are active. A HIGH on an En...
ACS240MS
The Radiation Hardened ACS240MS is an Inverting, Octal,Three-State Buffer/Line Driver with two active-LOW Enable inputs (AE and BE). Each Enable input controls four outputs.When an Enable input is LOW, the corresponding outputsare active and input signals ar...
ACS-229
