General Description
ACT11013 General Description
The 74AC/ACT11013 high-performance CMOS devices comparable very high speed and high output drive compa-rable to the most advanced TTl families
The 74AC/ACT11013 provides two sparate 4-input NAND gate functions which are capable of transforming slowly changing input signals into sharply defined,jitter-free output sig-nals.in addition,they have greater noise margin than conventional NAND gates.
ACT11013 Maximum Ratings
| SYMBOL | PAPAMETER | TEST CONDITIONS | RATING | UNIT |
| VCC | dc supply voltage | -0.5 to +0.7 | v | |
| Iik OR Vi | dc input diode current2 | vi<0 | -20 | ma |
| vi>vcc | 20 | |||
| dc input voltage | -0.5 tovcc+0.5 | v | ||
| Iok OR Vo | dc output diode current2 | Vo<0 | -50 | ma |
| Vo>Vcc | 50 | |||
| dc output voltage | -0.5to Vcc+0.5 | V | ||
| Io | dc output source or sink cirrent per output pin | Vo=0 to Vcc | ±50 | ma |
| Icc or Ieng | DC Vcc current | ±200 | ma | |
| DC ground current | ±200 | |||
| Tstg | storage temperature | -65 to 150 | ||
| Ptot | power dissipation per package | Above 70; derate linearly by 8mW/K | 500 | mW |
|
power dissipation per package plastic surface mount (SO) |
Above 70; derate linearly by 8mW/K | 400 | mW |
ACT11013 Features
OUtput capability:±24 ma
CMOS(AC)and TTL(ACT) voltage level inputs
50 incident wave switching
center-pin vcc and ground configu-ration to minimize high-speed switch-ing noise
lcc actegory:SSL
CMOS(AC)and TTL(ACT) voltage level inputs
50 incident wave switching
center-pin vcc and ground configu-ration to minimize high-speed switch-ing noise
lcc actegory:SSL
ACT11013 Connection Diagram
