Part Number: AD404M42VSA5
Description: The device CMOS Dynamic RAM organized as 4,194,304 words x 4 bits with extended data out ...
- Table of contents:
AD404M42VSA5
-
Suppliers
DataSheet
General Description
AD404M42VSA5 General Description
The device CMOS Dynamic RAM organized as 4,194,304 words x 4 bits with extended data out access mode. It is fabricated with an advanced submicron CMOS technology and designed to operate from a single 3.3V oniy power supply. Low voltage operation is more suitable to be used on battery backup, portable elec-tronic application. lt is packaged in JEDEC standard 26/24-pin plastic SOJ or TSOP(II).
AD404M42VSA5 Maximum Ratings
| Parameter | Symbol | Value | Unit |
| Voltage on any pin relative to Vss | VT | -0.5 to + 4.6 | V |
| Supply voltage relative to Vss | VCC | -0.5 to + 4.6 | V |
| Short circuit output current | IOUT | 50 | mA |
| Power dissipation | PD | 1.0 | W |
| Operating temperature | TOPT | 0 to + 70 | °C |
| Storage temperature | TSTG | -55 to + 125 | °C |
AD404M42VSA5 Features
* Single 3.3V(±10%) only power supply
* High speed tRAC acess time: 50/60ns
* Low power dissipation
- Active mode : 432/396 mW (Mas)
- Standby mode: 0.54 mW (Mas)
* Extended - data - out(EDO) page mode access
* I/O level: CMOS level (Vcc = 3.3V)
* 2048 refresh cycle in 32 ms(Std.) or 128 ms(S-version)
* 4 refresh modesh:
- RAS only refresh
- CAS - before - RAS refresh
- Hidden refresh
- Self-refresh(S-version)
* High speed tRAC acess time: 50/60ns
* Low power dissipation
- Active mode : 432/396 mW (Mas)
- Standby mode: 0.54 mW (Mas)
* Extended - data - out(EDO) page mode access
* I/O level: CMOS level (Vcc = 3.3V)
* 2048 refresh cycle in 32 ms(Std.) or 128 ms(S-version)
* 4 refresh modesh:
- RAS only refresh
- CAS - before - RAS refresh
- Hidden refresh
- Self-refresh(S-version)
AD404M42VSA5 Connection Diagram
