Part Number: AD5025



MFG: ADI



D/C: 09

Description: The AD5025/AD5045/AD5065 are low power, dual 12-/14-/16-bitbuffered voltage output nanoDAC? DACs offering relative accuracy specifications...


Urgent Purchase

AD5025 General Description


The AD5025/AD5045/AD5065 are low power, dual 12-/14-/16-bitbuffered voltage output nanoDAC? DACs offering relative accuracy specifications of ±1 LSB INL with individual reference pins, and can

AD5025 Maximum Ratings

Resolution (Bits) 12bit
DAC Settling Time 10.7s
# DAC Outputs 2
DAC Type Voltage Out
DAC Input Format Ser,SPI
Output FSR (Uni Vdd),(Uni Vref)
Ref Int/Ext Ext
Supply Vnom Single(+5)
Pwr Diss 13.5mW
Package SOP

AD5025 Connection Diagram

AD5025 Connection Diagram
