Purchase AD5680, In-stock AD5680 From SeekIC.
MFG:ADI D/C:09
Part Number: AD5680
MFG: ADI
D/C: 09
Description: The AD5680, a member of the nanoDAC family, is a single, 18-bit buffered voltage-out digital-to-analog converter that operates f...
- Table of contents:
AD5680
-
Suppliers
DataSheet
General Description
AD5680 General Description
The AD5680, a member of the nanoDAC family, is a single, 18-bit buffered voltage-out digital-to-analog converter that operates from a single 4.5 V to 5.5 V supply and is 18-bit monotonic.
AD5680 Maximum Ratings
| Resolution (Bits) | 18bit |
| DAC Update Rate | 12.5kSPS |
| DAC Settling Time | 80s |
| # DAC Outputs | 1 |
| DAC Type | Voltage Out |
| DAC Input Format | Ser,SPI |
| Output FSR | (Uni Vref) |
| Ref Int/Ext | Ext |
| Supply Vnom | Single(+5) |
| Pwr Diss | 2.25mW |
| Package | SOT |
AD5680 Connection Diagram
AD500-9
