General Description
AD7399 General Description
The AD7398/AD7399 family of quad, 12-bit/10-bit, voltage output digital-to-analog converters (DACs) is designed to operate from a single 3 V to 5 V supply or a dual ±5 V supply. Built with the
AD7399 Maximum Ratings
| Resolution (Bits) | 10bit |
| DAC Update Rate | 167kSPS |
| DAC Settling Time | 6s |
| # DAC Outputs | 4 |
| DAC Type | Voltage Out |
| DAC Input Format | Ser,SPI |
| Output FSR | (Uni Vref) |
| Ref Int/Ext | Ext |
| Supply Vnom | Dual(+5, -5),Single(+3),Single(+3.3),Single(+5) |
| Pwr Diss | 27mW |
| Package | SOIC,SOP |
AD7399 Connection Diagram
