Purchase AD7631, In-stock AD7631 From SeekIC.
MFG:ADI D/C:09
Part Number: AD7631
MFG: ADI
D/C: 09
Description: The AD7631 is an 18-bit, charge redistribution, successive approximation register (SAR), architecture analog-to-digital converter (ADC)...
- Table of contents:
AD7631
-
Suppliers
DataSheet
General Description
AD7631 General Description
The AD7631 is an 18-bit, charge redistribution, successive approximation register (SAR), architecture analog-to-digital converter (ADC) fabricated on Analog Devices, Inc.'s iCMOS high
AD7631 Maximum Ratings
| Resolution (Bits) | 18bit |
| T-Put Rate | 250kSPS |
| # Chan | 1 |
| Supply V | Multi(±15, +5) |
| Pwr Diss (max) | 120mW |
| Interface | Par,Ser,SPI |
| Ain Range | 10V p-p,20 V p-p,40 V p-p |
| SNR (dB) | 100dB |
| Pkg Type | CSP,QFP |
AD7631 Connection Diagram
