Purchase AD7658-1, In-stock AD7658-1 From SeekIC.
MFG:ADI D/C:09
Part Number: AD7658-1
MFG: ADI
D/C: 09
Description: The AD7656-1/AD7657-1/AD7658-11 are reduced decoupling pin- and software-compatible versions of AD7656/AD7657/AD7658. The AD765...
- Table of contents:
AD7658-1
-
Suppliers
DataSheet
General Description
AD7658-1 General Description
The AD7656-1/AD7657-1/AD7658-1
AD7658-1 Maximum Ratings
| Resolution (Bits) | 12bit |
| T-Put Rate | 250kSPS |
| # Chan | 6 |
| Supply V | (±15, +5An, +5Dig, +3Drv),(±15, +5An, +5Dig, +5Drv),(±5, +5An, +5Dig, +3Drv),(±5, +5An, +5Dig, +5Drv) |
| Pwr Diss (max) | 140mW |
| Interface | Par,Ser,SPI |
| Ain Range | 10V p-p,20 V p-p,Bip 10V,Bip 20V |
| SNR (dB) | n/a |
| Pkg Type | QFP |
AD7658-1 Connection Diagram
