Part Number: AD9116



MFG: ADI



D/C: 09

Description: The AD9114/AD9115/AD9116/AD9117 are pin-compatible dual, 8-/10-/12-/14-bit, low power digital-to-analog converters (DACs) that provide a s...


Urgent Purchase

AD9116 General Description


The AD9114/AD9115/AD9116/AD9117 are pin-compatible dual, 8-/10-/12-/14-bit, low power digital-to-analog converters (DACs) that provide a sample rate of 125 MSPS. These TxDAC? converters are optimized

AD9116 Maximum Ratings

Resolution (Bits) 12bit
DAC Update Rate 125MSPS
DAC Settling Time n/a
# DAC Outputs 4
DAC Type Current Out
DAC Input Format Par
Output FSR (0-20mA),(0-4mA)
Ref Int/Ext Int/Ext
Supply Vnom Single(+1.8 to +3.3)
Pwr Diss n/a
Package CSP

AD9116 Connection Diagram
