Purchase AD9889B, In-stock AD9889B From SeekIC.
MFG:ADI D/C:09
Part Number: AD9889B
MFG: ADI
D/C: 09
Description: The AD9889B is a 165 MHz, high definition multimedia inter-face (HDMI™) v. 1.3 transmitter. It supports HDTV formats up to 1080p, an...
- Table of contents:
AD9889B
-
Suppliers
DataSheet
General Description
AD9889B General Description
The AD9889B is a 165 MHz, high definition multimedia inter-face (HDMI™) v. 1.3 transmitter. It supports HDTV formats up to 1080p, and computer graphic resolutions up to UXGA (1600 × 1200 @ 60
AD9889B Maximum Ratings
| Color Depth (bits) | 8bit |
| Function | HDMI/DVI Xmitter |
| HDCP Key | External |
| I2S Audio Channels | 8 |
| Max Resolution | 1080p/UXGA |
| Pixel Clock (MHz) | 165MHz |
| Resolution (Bits) | 8bit |
| Package | 64-LFCSP,76-BGA,80-LQFP |
| Sample Rate (MSPS) | 0 |
| SPDIF | X |
AD9889B Connection Diagram
