Features: AD9891: 10-Bit 20 MHz VersionAD9895: 12-Bit 30 MHz VersionCorrelated Double Sampler (CDS)4 6 dB Pixel Gain Amplifier (PxGA )(R)2 dB to 36 dB 10-Bit Variable Gain Amplifier (VGA)10-Bit 20 MHz A/D Converter (AD9891)12-Bit 30 MHz A/D Converter (AD9895)Black Level Clamp with Variable Level C...
AD9895: Features: AD9891: 10-Bit 20 MHz VersionAD9895: 12-Bit 30 MHz VersionCorrelated Double Sampler (CDS)4 6 dB Pixel Gain Amplifier (PxGA )(R)2 dB to 36 dB 10-Bit Variable Gain Amplifier (VGA)10-Bit 20 M...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Parameter |
With RespectTo | Min | Max | Unit |
AVDD1, AVDD2 TCVDD HVDD RGVDD DVDD DRVDD RG Output H1H4 Output Digital Outputs Digital Inputs SCK, SL, SDATA VRT, VRB BYP1BYP3, CCDIN Junction Temperature Lead Temperature, 10 sec |
AVSS TCVSS HVSS RGVSS DVSS DRVSS RGVSS HVSS DVSS DVSS DVSS AVSS AVSS |
0.3 |
+3.9 +3.9 +5.5 +5.5 +3.9 +3.9 RGVDD + 0.3 HVDD + 0.3 DVDD + 0.3 DVDD + 0.3 DVDD + 0.3 AVDD + 0.3 AVDD + 0.3 150 350 |
V V V V V V V V V V V V V °C °C |
The AD9891 and AD9895 are highly integrated CCD signal processors for digital still camera applications. Both include a complete analog front end with A/D conversion combined with a full-function programmable timing generator. A Precision Timing core allows adjustment of high speed clocks with 1 ns resolution at 20 MHz operation and 700 ps resolution at 30 MHz operation.
The AD9891 is specified at pixel rates of up to 20 MHz, and the AD9895 is specified at 30 MHz. The analog front end includes black level clamping, CDS, PxGA, VGA, and a 10-Bit or 12-Bit A/D converter. The timing generator provides all the necessary CCD clocks: RG, H-clocks, V-clocks, sensor gate pulses, substrate clock, and substrate bias control. Operation is programmed using a 3-wire serial interface. Packaged in a space-saving 64-lead CSPBGA, the AD9891 and
AD9895 are specified over an operating temperature range of 20°C to +85°C.
