ADAV803
-
Suppliers
DataSheet
General Description
ADAV803 Maximum Ratings
| Parameter | Rating |
| DVDD to DGND and ODVDD to DGND AVDD to AGND Digital Inputs Analog Inputs AGND to DGND Reference Voltage Soldering (10 s) |
0 V to 4.6 V 0 V to 4.6 V DGND − 0.3 V to DVDD + 0.3 V AGND − 0.3 V to AVDD + 0.3 V −0.3 V to +0.3 V Indefinite short circuit to ground 300°C |
ADAV803 Features
Stereo analog-to-digital converter (ADC)
Supports 48/96 kHz sample rates
102 dB dynamic range
Single-ended input
Automatic level control
Stereo digital-to-analog converter (DAC)
Supports 32/44.1/48/96/192 kHz sample rates
101 dB dynamic range
Single-ended output
Asynchronous operation of ADC and DAC
Stereo sample rate converter (SRC)
Input/output range: 8 kHz to 192 kHz
140 dB dynamic range
Digital interfaces
Record
Playback
Auxiliary record
Auxiliary playback
Supports 48/96 kHz sample rates
102 dB dynamic range
Single-ended input
Automatic level control
Stereo digital-to-analog converter (DAC)
Supports 32/44.1/48/96/192 kHz sample rates
101 dB dynamic range
Single-ended output
Asynchronous operation of ADC and DAC
Stereo sample rate converter (SRC)
Input/output range: 8 kHz to 192 kHz
140 dB dynamic range
Digital interfaces
Record
Playback
Auxiliary record
Auxiliary playback
ADAV803 Typical Application
DVD-recordable All formats CD-R/W
