Purchase ADG1233, In-stock ADG1233 From SeekIC.
MFG:ADI D/C:09
Part Number: ADG1233
MFG: ADI
D/C: 09
Description: The ADG1233 is a monolithic iCMOS analogswitch comprising of three independently selectable singlepole, double throw (SPDT) swit...
- Table of contents:
ADG1233
-
Suppliers
DataSheet
General Description
ADG1233 General Description
The ADG1233 is a monolithic iCMOS analogswitch comprising of three independently selectable singlepole, double throw (SPDT) switches.All channels exhibit break-before-make switching
ADG1233 Maximum Ratings
| Switch Type | SPDT |
| # Channels | 3 |
| Ron (Ohms) | 120Ohms |
| Id, Is (ON) | 20pA |
| Bandwidth | 900MHz |
| t ON | 120ns |
| t OFF | 40ns |
| Supply Voltage | Dual (±15V),Single (+12V) |
ADG1233 Connection Diagram
