ADG509AKPZ

ADG Series Datasheet download

Five Points

Part Number: ADG509AKPZ

Category: Integrated Circuits (ICs)

MFG: Analog Devices Inc





Descriptions: IC MUX ANALOG DUAL 4CH 20PLCC

Price Break

98

Unit Price

4.26602

Extended Price

418.07

(All prices are in USD) Prices for reference only
Urgent Purchase

ADG509AKPZ General Description

IC MUX ANALOG DUAL 4CH 20PLCC

ADG509AKPZ Parameters

Technical/Catalog InformationADG509AKPZ
VendorAnalog Devices Inc
CategoryIntegrated Circuits (ICs)
TypeMultiplexer
Voltage Supply SourceDual Supply
Voltage - Supply, Single/Dual (±)±10.8 V ~ 16.5 V
Circuit2 x 4:1
On-State Resistance300 Ohm
Mounting TypeSurface Mount
Package / Case20-PLCC
Packaging-
Current - Supply20A
Operating Temperature-40°C ~ 85°C
FunctionMultiplexer
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names ADG509AKPZ
ADG509AKPZ

ADG509AKPZ datasheet

ADG1204
