MFG:Analog Devices Inc. Category:ICs, Modules, Accessories for RF, RFID
Category: ICs, Modules, Accessories for RF, RFID
MFG: Analog Devices Inc.
Descriptions: IC MODULATOR RADIO LINK 24-LFCSP
| Technical/Catalog Information | ADL5385ACPZ-WP |
| Vendor | Analog Devices Inc. |
| Category | ICs, Modules, Accessories for RF, RFID |
| Mounting Type | Surface (SMD, SMT) |
| Package Name | 24-LFCSP |
| Typical RF Application | WLL |
| Typical RF Application | 802.16/WiMax |
| Typical RF Application | Broadcast Television |
| Frequency | 50.000 MHz [Min] |
| Frequency | 2.200 GHz [Max] |
| Modulation Type | I/Q |
| Supply Voltage | 5.00 V [Typ] |
| Supply Current | 215.000 mA [Typ] |
| Operating Temperature | -40 °C [Min] |
| Operating Temperature | 85 °C [Max] |
| Type | Modulator |
| Packaging | Tray |
| Length | 3.750 mm [Typ] |
| Width | 4.000 mm [Typ] |
| Thickness | 0.8000 mm [Min] |
| Thickness | 1.0000 mm [Max] |
| Thickness | 0.8500 mm [Typ] |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | ADL5385ACPZ WP ADL5385ACPZWP |
ADL5306
PDF/DataSheet Download
IC QUADRATURE MOD 50MHZ 24LFCSP
The ADL5385 is a silicon, monolithic, quadrature modulator designed for use from 50 MHz to 2200 MHz. Its excellent phase accuracy and amplitude balance enable both high performance intermediate frequency (IF) and direct radio frequency (RF) modulation for co...
IC DEMOD QUAD 700M2.7GHZ 24LFCSP
IC DEMOD QUAD .4/6GHZ 24LFCSP
Excellent quadrature accuracy is achieved using on-chip poly-phase filters for LO quadrature generation. Over a wide range of local oscillator (LO) levels, excellent demodulation accuracy is achieved in ADL5380. The ADL5380 is a high performance quadrature ...
IC MOD QUAD 400MHZ-6GHZ 24LFCSP
