ADP150

The ADP150 is designed as one kind of ultralow noise, 150 mA CMOS linear regulator device that can be used in wide range of applications such as (1)Mobile phones; (2)Digital camera and audio devices; (3)Portable and battery-powered equipment; (4)Post dc-to-dc regulation; (5)Portable medical devices; (6)RF, PLL, VCO, and clock power supplies. And this device is available in 14 fixed output voltage options, ranging from 1.8 V to 3.3 V.

Features of the ADP150 are:(1)Low shutdown current: <1 A; (2)Low dropout voltage: 105 mV @ 150 mA load; (3)Initial output voltage accuracy: ±1%; (4)Up to 14 fixed output voltage options: 1.8 V to 3.3 V; (5)PSRR performance of 70 dB at 10 kHz; (6)Current limit and thermal overload protection; (7)Logic-controlled enable; (8)5-lead TSOT package; (9)4-ball, 0.8 mm * 0.8 mm, 0.4 mm pitch WLCSP; (10)Ultra low noise: 9 V rms, independent of VOUT; (11)No additional noise bypass capacitor required; (12)Stable with 1 F ceramic input and output capacitors; (13)Maximum output current: 150 mA; (14)Input voltage range: 2.2 V to 5.5 V.

The absolute maximum ratings of the ADP150 can be summarized as:(1)VIN to GND: -0.3 V to +6.5 V;(2)VOUT to GND: -0.3 V to VIN;(3)EN to GND: -0.3 V to +6.5 V;(4)Storage Temperature Range: -65°C to +150°C;(5)Operating Junction Temperature Range: -40°C to +125°C;(6)Operating Ambient Temperature Range: -40°C to +85°C;(7)Soldering Conditions: JEDEC J-STD-020. If you want to know more information about the ADP150, please download the datasheet in www.seekic.com or www.chinaicmart.com .
