Part Number: ADP3303



MFG: AD

Package Cooled: SOP

D/C: 0625+

Description: The ADP3303 is a member of the ADP330x family of precisionlow dropout anyCAP? voltage regulators. The ADP3303stands out from the conventio...


Urgent Purchase

ADP3303 General Description


The ADP3303 is a member of the ADP330x family of precisionlow dropout anyCAP? voltage regulators. The ADP3303stands out from the conventional LDOs with a novel architec-ture,an enhanced process and

ADP3303 Maximum Ratings

Vout Preset 5 Presets From 2.7-5V
Vout Adj Range n/a
Vin Range (Vmin to Vmax) 3.2 to 12
Iout (max) 200mA
Supply Current 0.4mA
Vdropout @ Rated Iout 180mV to 400mV
Vout Total Acc 1.4% @ 0.1 mA - Iout max
Package SOIC-8
# of Outputs 1
Line Regulation 0.01mV/V
Load Regulation 0.013mV/mA
Shutdown Yes
Operating Temp Range -20 to +85

ADP3303 Connection Diagram

ADP3303 Connection Diagram
