ADR3412

The ADR3412 is designed as one kind of low cost, low power, high precision CMOS voltage reference device that can be used in wide range of applications such as (1)precision data acquisition systems; (2)industrial instrumentation; (3)medical devices; (4)battery-powered devices. Also this device is available in a wide range of output voltages, all of which are specified over the industrial temperature range of -40°C to +125°C.

Features of the ADR3412 are:(1)Initial accuracy: ±0.1% (maximum); (2)Maximum temperature coefficient: 8 ppm/°C; (3)Operating temperature range: .40°C to +125°C; (4)Output current: +10 mA source/.3 mA sink; (5)Low quiescent current: 100 A (maximum); (6)Low dropout voltage: 250 mV at 2 mA; (7)Output noise (0.1 Hz to 10 Hz): <10 V p-p at 1.2 V (typical); (8)6-lead SOT-23.

The absolute maximum ratings of the ADR3412 can be summarized as:(1)Junction Temperature Range: -65°C to +150°C;(2)VIN Minimum Slew Rate: 0.1 V/ms;(3)Storage Temperature Range: -65°C to +125°C;(4)Operating Junction Temperature Range: -40°C to +125°C;(5)ENABLE to GND SENSE Voltage: VIN;(6)Supply Voltage: 6 V.etc. If you want to know more information about the ADR3412, please download the datasheet in www.seekic.com or www.chinaicmart.com .
