Features: •JEDEC standard LVTTL 3.3V power supply•MRS Cycle with address key programs-CAS Latency (2 & 3)-Burst Length (1,2,3,8,& full page)-Burst Type (sequential & Interleave)•4 banks operation•All inputs are sampled at the positive edge of the system clock...
ADS6616A4A: Features: •JEDEC standard LVTTL 3.3V power supply•MRS Cycle with address key programs-CAS Latency (2 & 3)-Burst Length (1,2,3,8,& full page)-Burst Type (sequential & Interlea...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
US $199.25 - 199.25 / Piece
Data Conversion IC Development Tools ADS6122 Eval Mod
Parameter | Symbol | Value | Unit |
Voltage on any pin relative to Vss | VIN, VOUT | -0.3 ~ VDD+0.3 | V |
Voltage on VDD supply relative to Vss | VDD, VDDQ | -0.3 ~ 4.6 | V |
Storage temperature | TSTG | -55 ~ +150 | |
Power dissipation | PD | 1 | W |
Short circuit current | IOS | 50 | mA |
The ADS6616A4A are four-bank Synchronous DRAMs organized as 1,048,576 words x 16 bits x 4 banks, Synchronous design allows precise cycle control with the use of system clock I/O transactions are possible on every clock cycle. Range of operating frequencies, programmable burst length and programmable latencies allow the same device to be useful for a variety of high bandwidth high performance memory system applications
