Part Number: ADS7616A4A
Description: The ADS7616A4A are four-bank Synchronous DRAMs organized as 2,097152 words x 16 bits x 4 banks.
- Table of contents:
ADS7616A4A
-
Suppliers
DataSheet
General Description
ADS7616A4A General Description
The ADS7616A4A are four-bank Synchronous DRAMs organized as 2,097152 words x 16 bits x 4 banks.
Synchronous design allows precise cycle control with the use of system clock I/O transactions are possible on every clock cycle. Range of operating frequencies, programmable burst length and programmable latencies allow the same device to be useful for a variety of high bandwidth high performance memory system applications
ADS7616A4A Maximum Ratings
| Parameter | Symbol | Value | Unit |
| Voltage on any pin relative to Vss | VIN, VOUT | -0.3 ~ VDD+0.3 | V |
| Voltage on VDD supply relative to Vss | VDD, VDDQ | -0.3 ~ 4.6 | V |
| Storage temperature | TSTG | -55 ~ +150 | |
| Power dissipation | PD | 1 | W |
| Short circuit current | IOS | 50 | mA |
Functional operation should be restricted to recommended operating condition.
Exposure to higher than recommended voltage for extended periods of time could affect device reliability.
ADS7616A4A Features
•JEDEC standard LVTTL 3.3V power supply
•MRS Cycle with address key programs
-CAS Latency (2 & 3)
-Burst Length (1,2,4,8,& full page)
-Burst Type (sequential & Interleave)
•4 banks operation
•All inputs are sampled at the positive edge of the system clock
•Burst Read single write operation
•Auto & Self refresh
•4096 refresh cycle
•DQM for masking
•Package:54-pins 400 mil TSOP-Type II
•MRS Cycle with address key programs
-CAS Latency (2 & 3)
-Burst Length (1,2,4,8,& full page)
-Burst Type (sequential & Interleave)
•4 banks operation
•All inputs are sampled at the positive edge of the system clock
•Burst Read single write operation
•Auto & Self refresh
•4096 refresh cycle
•DQM for masking
•Package:54-pins 400 mil TSOP-Type II
ADS7616A4A Connection Diagram
ADS7616A4A
PDF/DataSheet Download
- Datasheet: ADS7616A4A
- File Size: 578948 KB
- Manufacturer: A-DATA [A-Data Technology]
- Click here to Download
