ADS7823EB(B23)

The ADS7823EB is one member of the ADS7823 family which is designed as the 12-bit, sampling A/D converter that can be used in wide range of applications such as (1)voltage supply monitoring; (2)isolated data acquisition; (3)transducer interface; (4)battery-operated systems; (5)remote data acquisition. And this device features a sample-andhold amplifier and internal, asynchronous clock.

Features of the ADS7823EB are:(1)50kHz sampling rate; (2)no missing codes; (3)2.7V to 5V operation; (4)four-word filo; (5)A0, A1 address pins; (6)I2C interface supports: standard, fast, and high-speed modes; (7)MSOP-8 package.

The absolute maximum ratings of the ADS7823EB can be summarized as:(1)+VDD to GND: -0.3 V to +6 V;(2)Digital Input Voltage to GND: -0.3V to +VDD + 0.3V;(3)Analog Input Voltage to GND: 0.3V to +6.0V;(4)Operating Temperature Range: 40°C to +85°C;(5)Storage Temperature Range: 65°C to +150°C;(6)Junction Temperature (TJ max): +150°C;(7)Power Dissipation: (TJ max TA)/JA;(8)Lead Temperature, Soldering Vapor Phase (60s): +215°C;(9)Lead Temperature, Soldering Infrared (15s): +220°C. If you want to know more information such as the electrical characteristics about the ADS7823EB, please download the datasheet in www.seekic.com or www.chinaicmart.com.
