ADS7852Y

The ADS7852Y is designed as an 8-channel, 12-bit analog-to-digital (A/D) converter complete with sample-and-hold, internal 2.5V reference and a full 12-bit parallel output interface. Typical power dissipation is 13mW at at 500kHz throughput rate.

ADS7852Y has nine features. (1)2.5V internal reference. (2)8 input channels. (3)500KHz sampling rate. (4)Single 5V supply. (5)+/-1LSB: INL, DNL. (6)Guaranteed no missing codes. (7)70dB SINAD. (8)Low power 13mW. (9)TQFP-32 package. Those are all the main features.

Some absolute maximum ratings of ADS7852Y have been concluded into several points as follow. (1)Its analog inputs to AGND, any channel input would be from -0.3V to Vd+0.3V. (2)Its REFin would be from -0.3V to Vd+0.3V. (3)Its digital inputs to DGND would be from -0.3V to Vd+0.3V. (4)Its ground voltage differences: AGND, DGND would be +/-0.3V. (5)Its +Vss to AGND would be from -0.3V to 6V. (6)Its power dissipation would be 325mW. (7)Its maximum junction temperature would be 150°C. (8)Its operating temperature range would be from -40°C to 85°C. (9)Its storage temperature range would be from -65°C to 150°C. (10)Its lead temperature soldering 10s would be 300°C. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to device.

Also some electrical characteristics of ADS7852Y are concluded as follow. (1)Its resolution would be max 12bits. (2)Its input voltage range would be min 0V and max 5V. (3)Its input impedance would be typ 5Mohms. (4)Its input capacitance would be typ 15pF. (5)Its input leakage current would be typ +/-1uA. (6)Its no missing codes would be min 12bits. (7)Its digital input high voltage would be min 3V and max Vss+0.3V. (8)Its input low voltage would be min -0.3V and max 0.8V. (9)Its output high voltage would be min 3.5V. (10)Its output low voltage would be max 0.4V. (11)Its reference input range would be min 2.0V and max 2.55V. And so on. If you have any question or suggestion or want to know more information about ADS7852Y, please contact us for details. Thank you!
