ADXRS652

The ADXRS652 is designed as one kind of complete angular rate sensor (gyroscope) device that can be used in (1)Industrial applications; (2)Inertial measurement units; (3)Platform stabilization applications. And this device is available in a 7 mm × 7 mm × 3 mm BGA chip-scale package.

Features of the ADXRS652 are:(1)Complete rate gyroscope on a single chip; (2)Z-axis (yaw rate) response; (3)High vibration rejection over wide frequency; (4)2000 g powered shock survivability; (5)Ratiometric to referenced supply; (6)5 V single-supply operation; (7).40°C to +105°C operation; (8)Self-test on digital command; (9)Ultrasmall and light (<0.15 cc, <0.5 gram); (10)Temperature sensor output; (11)RoHS compliant.

The absolute maximum ratings of the ADXRS652 can be summarized as:(1)Acceleration (Any Axis, 0.5 ms) Unpowered: 2000 g;(2)VDD, AVCC: -0.3 V to +6.0 V;(3)VRATIO: AVCC;(4)ST1, ST2: AVCC;(5)Output Short-Circuit Duration (Any Pin to Common): Indefinite;(6)Operating Temperature Range: -55°C to +125°C;(7)Storage Temperature Range: -65°C to +150°C. If you want to know more information about the ADXRS652, please download the datasheet in www.seekic.com or www.chinaicmart.com .
