AF16B0050

The AF16B0050 is designed as one kind of 5.5MHz video delay lines. This range of video delay lines is designed to delay 5.5 MHz bandwidth video signals with minimum distortion. This range is fully phase equalised and give excellent response to pulse and bar test signals. AF16B0050 may be cascaded to give a wider range of delay times. Other delay times within the range can be produced to special order.

AF16B0050 has four features. (1)Fixed and programmable versions. (2)Excellent pulse characteristics. (3)Small size. (4)Low insertion loss. Those are all the main features.

Some important electrical characteristics of AF16B0050 are concluded into several points as follow. (1)Its delay time would be 50ns. (2)Its insertion loss would have the maximum value of 0.2dB. And so on.

And also some other important data of AF16B0050 are concluded into sveral points as follow. (1)impedance would be 75ohms. (2)Its tolerance on pulse delay time would be +/-2% or +/-2ns (which ever is greater). (3)Its amplitude ripple to 5.5MHz would have the maximum value of 0.1dB up to 500ns and would have the maximum value of 0.2dB at 1000ns. (4)Its group delay ripple would have the maximum value of +/-5ns up to 500ns and would have the maximum value of +/-10ns up to 1000ns. (5)Its return loss to 5.5MHz would have the minimum value of 27dB to 400ns and would have the minimum value of 25dB to 1000ns. (6)Its pulse and bar k-rating, 2T would have the maxium value of 0.5%. (7)Its luminance or chrominance gain inequality (20T) would have the maximum value of 1%. (8)Its luminance or chrominance delay inequality (20T) would have the maximum value of 5ns. (9)Its aqueous washable would be yes. (10)Its temperature range would be from 0°C to 70°C. And so on. At present we have not got so much information about this IC and we would try hard to get more information about AF16B0050. If you have any question or suggestion please visit our website and contact us for details. Thank you!
