See larger image

SeekIC No. : 003439215 Detail

AFB1212VHE-F00: FAN DC AXIAL 12V 120X38 TAC OUT

AFB1212VHE-F00 Data Sheet

US $ 5.51~10.79 / Piece | Get Latest Price

Part Number:: AFB1212VHE-F00
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~1
1~10
10~25
25~50
50~100
100~250
250~500
500~1000

Unit Price
$10.79
$9.87
$8.26
$7.57
$6.66
$6.2
$5.74
$5.51

Processing time
15 Days
15 Days
15 Days
15 Days
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

AFB1212GHE-CF00 evaluate
US $8.57 - 16.78 / Piece

12V DC FAN 120X120X38 MM
AFB1212H evaluate
US $4.75 - 9.31 / Piece

FAN DC AXIAL 12V 120X25.4 2500
AFB1212HE evaluate
US $5.33 - 10.43 / Piece

12V DC FAN 120X120X38 MM

Product Details

Quick Details

Series:	AFB	Manufacturer:	Delta Product Groups
Fan Type:	Tubeaxial	Size / Dimension:	Square - 120mm L x 120mm H x 38mm W
Voltage - Rated:	12VDC	Power (Watts):	8.16W
Features:	Speed Sensor (Tach)	RPM:	4000 RPM
Noise:	51 dB(A)	Static Pressure:	0.602 in H2O (149.9 Pa)
Package / Case :	SOT-393	Air Flow:	148.3 CFM (4.20m³/min)
Termination:	3 Wire Leads	Bearing Type:	Ball

Description

Fan Type: Tubeaxial
Voltage - Rated: 12VDC
Operating Temperature: -
Bearing Type: Ball
Features: Speed Sensor (Tach)
Termination: 3 Wire Leads
RPM: 4000 RPM
Size / Dimension: Square - 120mm L x 120mm H x 38mm W
Power (Watts): 8.16W
Noise: 51 dB(A)
Static Pressure: 0.602 in H2O (149.9 Pa)
Manufacturer: Delta Product Groups
Series: AFB
Air Flow: 148.3 CFM (4.20m³/min)

Parameters:

Technical/Catalog Information	AFB1212VHE-F00
Vendor	Delta Product Groups
Category	Fans, Thermal Management
Voltage - Rated	12VDC
Power (Watts)	7.2W
Bearing Type	Ball
Size / Dimension	Square - 120mm L x 120mm H x 38mm W
Air Flow	129.9 CFM
Features	Speed Sensor (Tach)
Termination	3 Wire Leads
Fan Type	Tubeaxial
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	AFB1212VHE F00 AFB1212VHEF00 603 1078 ND 6031078ND 603-1078
