AIC811/812

AIC811/AIC812 are low-power microprocessor (gP) supervisory circuits used to monitor power supplies in gP and digital systems. They provide applications with benefits of circuit reliability and low cost by eliminating external components. AIC811/AIC812 also offer a manual reset input.

These devices perform as valid singles in applications with Vcc ranging from 6.0V down to 0.9V. The reset signal lasts for a minimum period of 140ms whenever VCC supply voltage falls below preset threshold. Both AIC811 and AIC812 were designed with a reset comparator to help identify invalid signals, which last less than 140ms. The only difference between them is that they have an active-low   output and active-high RESET output, respectively.

Low supply current (1uA) makes AIC811/AIC812 ideal for portable equipment. The devices are available in SOT-23-5 package.
