Purchase AK61584, In-stock AK61584 From SeekIC.
Part Number: AK61584
Description: The AK61584 is a universal line interface for T1/E1 applications,designed for high-volume cards where low power,hig...
- Table of contents:
AK61584
-
Suppliers
DataSheet
General Description
AK61584 General Description
The AK61584 is a universal line interface for T1/E1 applications,designed for high-volume cards where low power,
high density and universal operation is required. One board design can support all T1/E1 modes.
The AK61584 is a low-power CMOS device available in 3.3 Volt.
AK61584 Features
- Provides Dual Analog PCM Line Interface for short-haul,T1 and E1 applications
- Jitter Tolerance: Compliant with AT&T62411 TR-NWT-000499 Category I,II ITU-T G.823
- Transmitter Pulse Shape: Compliant with AT&T62411,CB119, TR-NWT-000499,ITU-T G.703
- Jitter Transfer: AT&T62411, ITU-T G.736
- Operating mode fully software configurable.No external quartz crystal is required.
- Support of JTAG boundary scan
- Low Power Consumption
- 3.3Volt operation
- Small Plastic Package 64pin LQFP(10*10*1.4mm)
- Jitter Tolerance: Compliant with AT&T62411 TR-NWT-000499 Category I,II ITU-T G.823
- Transmitter Pulse Shape: Compliant with AT&T62411,CB119, TR-NWT-000499,ITU-T G.703
- Jitter Transfer: AT&T62411, ITU-T G.736
- Operating mode fully software configurable.No external quartz crystal is required.
- Support of JTAG boundary scan
- Low Power Consumption
- 3.3Volt operation
- Small Plastic Package 64pin LQFP(10*10*1.4mm)
AK61584
PDF/DataSheet Download
- Datasheet: AK61584
- File Size: 372834 KB
- Manufacturer: AKM [Asahi Kasei Microsystems]
- Click here to Download
