MFG:TO-223 Package Cooled:ANALOG MICROELECTRONICS D/C:03+
MFG: TO-223
Package Cooled: ANALOG MICROELECTRONICS
D/C: 03+
Description: The AME8805/8810 family of positive, linear regulators feature low quiescent current (30µA typ.)...
The AME8805/8810 family of positive, linear regulators feature low quiescent current (30µA typ.) with low drop-out voltage, making them ideal for battery applications.The space-saving SOT-89 and SOT-223 packages are attractive for "Pocket" and "Hand Held" applications.These rugged devices have both Thermal Shutdown,and Current Fold-back to prevent device failure under the"Worst" of operating conditions.The AME8805/8810 is stable with an output capaci-tance of 2.2µ F or greater.
| Parameter | Maximum | Unit |
| Input Voltage | 8 | V |
| Output Current | 1 | V |
| Input, Output Voltage | GND - 0.3 to VIN + 0.3 | V |
| ESD Classification | B |
AME8805
PDF/DataSheet Download
The AME8804 family of positive, linear regulators fea-ture low quiescent current (30µA typ.) with low dropout voltage, making them ideal for battery applications. The space-saving SOT-26 and SOT-25 packages are attrac- tive for "Pocket" and "Hand Held"...
The AME8803 family of positive, linear regulators feature low quiescent current (30A typ.) with low dropout voltage, making them ideal for battery applications. The space-saving SOT-23-6 package is attractive for "Pocket" and "Hand Held" applications. These...
The AME8803/8814 family of positive, linear regulators feature low quiescent current (30mA typ.) with low dropout voltage, making them ideal for battery applications.The space-saving SOT-26 package is attractive for "Pocket" and "Hand Held" applications.Thes...
The AME8802 family of positive, linear regulators fea- ture low quiescent current (30A typ.) with low dropout voltage, making them ideal for battery applications. The space-saving SOT-23-5 package is attractive for "Pocket" and "Hand Held" applications.These...
The AME8801/8840 family of CMOS regulators contain a PMOS pass transistor, voltage reference, error amplifier, over-current protection, and thermal shutdown.The P-channel pass transistor receives data from the error amplifier, over-current shutdown, and ther...
The AME8800/8811 family of positive, linear regula-tors feature low quiescent current (30µA typ.) with low dropout voltage, making them ideal for battery applica-tions. The space-saving SOT-23, SOT-25, SOT-89 and TO-92 packages are attractive for "Pock...
