AN15865A
-
Suppliers
DataSheet
General Description
AN15865A Maximum Ratings
| A No. |
Parameter | Symbol | Rating | Unit | Note |
| 1 | Supply voltage | V , V CC1 CC2 |
10.0 | V | *1 |
| V , V CC3 CC4 |
5.5 | ||||
| 2 | Supply current | I , I CC1 CC2 |
130 | mA | |
| I , I CC3 CC4 |
23 | ||||
| 3 | Power dissipation | P D |
773 | mW | *2 |
| 4 | Operating ambient temperature | D Topr |
-20 to +75 | *3 | |
| 5 | Storage temperature | Tstg | -55 to +125 | *3 |
AN15865A Features
1. Support multi scan / Auto format identification 480i, 576i, 480P, 576P, 720P, 1080i, 1152i, 1152i/letter (both 50 Hz & 60 Hz)
2. Field 1 or 2 monitor out is available
3. Auto distinction in the selected input (Sync on CV/Y or Sync on SY or no input signal)
4. Dummy sync output 480i, 576i, 480P, 576P, 720P, 1080i (both 50 Hz & 60 Hz)
5. Sync separation with AFC w/o external x-tal or clock
6. 2 values, 3 values sync identification
7. RGB YUV converter (CCIR standard, BTA standard, GBR matrix)
8. Each output can be switched between LPF (6 MHz) & through
9. Each output can be switched among 0 dB, 6 dB or mute
10. Macrovision
11. Comparators for Pin detection *4 (Connected / Open)
12. Comparators for Aspect ratio *4 (4:3 video / 4:3 letter box / 16:9 video)
13. High frequency (0 dB at 50 MHz)
14. Support the I C BUS
15. Various input mode can be selected by using flexible internal switch
2. Field 1 or 2 monitor out is available
3. Auto distinction in the selected input (Sync on CV/Y or Sync on SY or no input signal)
4. Dummy sync output 480i, 576i, 480P, 576P, 720P, 1080i (both 50 Hz & 60 Hz)
5. Sync separation with AFC w/o external x-tal or clock
6. 2 values, 3 values sync identification
7. RGB YUV converter (CCIR standard, BTA standard, GBR matrix)
8. Each output can be switched between LPF (6 MHz) & through
9. Each output can be switched among 0 dB, 6 dB or mute
10. Macrovision
11. Comparators for Pin detection *4 (Connected / Open)
12. Comparators for Aspect ratio *4 (4:3 video / 4:3 letter box / 16:9 video)
13. High frequency (0 dB at 50 MHz)
14. Support the I C BUS
15. Various input mode can be selected by using flexible internal switch
AN15865A Typical Application
IC for Color TV
AN15865A
PDF/DataSheet Download
- Datasheet: AN15865A
- File Size: 471563 KB
- Manufacturer: PANASONIC [Panasonic Semiconductor]
