Five Points

Parameter	Symbol	Ratio	Unit	Note
Storage temperature	Tstg	-55 to +150	ºC	1
Operating ambient temperature	Topr	-25 to +70	ºC	1
Supply voltage	Vcc	14	V	2
Supply current	Icc	1.0	A
Power dissipation	PD	AN7511 541 AN7511S 245	mW	Ta=70ºC

• AN7511: Vcc=5V,Output=1W(8W)
• AN7511S:Vcc=5V,Output=0.5W(16W)
• Built-in Standby function.
• Built-in Mute circuits.

• TVs, Audio equipment, Personal computers,Active speakers

AN7511S
