AN8539SH
-
Suppliers
DataSheet
General Description
AN8539SH Maximum Ratings
| Parameter | Symbol | Rating | Unit |
| Supply voltage | VCC | 3.6 | V |
| Supply current | ICC | 3.5 | mA |
| Power dissipation *2 | PD | 12.6 | mW |
| Operating ambient temperature*1 | Topr | -30 to +85 | °C |
| Storage temperature*1 | Tstg | -55 to +125 | °C |
AN8539SH Features
· To be switched to two frequencies.
(Select by SELECT pin.)
· Analog SW built-in
· ICC = 900 mA
(Select by SELECT pin.)
· Analog SW built-in
· ICC = 900 mA
AN8539SH Typical Application
· Cellular phone
AN8539SH
PDF/DataSheet Download
- Datasheet: AN8539SH
- File Size: 55540 KB
- Manufacturer: PANASONIC [Panasonic Semiconductor]
- Click here to Download
