Purchase AN8946SB, In-stock AN8946SB From SeekIC.
MFG:PASONIC Package Cooled:SOP
- Table of contents:
AN8946SB
-
Suppliers
DataSheet
General Description
AN8946SB Maximum Ratings
| Parameter | Symbol | Rating | Unit |
| Supply voltage | VCC | 5.6 | V |
| Supply current | ICC | 50 | mA |
| Power dissipation | PD | 280 | mW |
| Operating ambient temperature* | Topr | 20 to + 75 | °C |
| Storage temperature* | Tstg | 55 to + 150 | °C |
AN8946SB Features
· 5 V single power source
· Low power dissipation (typ. 170 mW)
· S/N 65 dB or more
· Inter-modulation interference ratio: 50 dB or more
· AGC amp built in (Reduction range: 55 dB)
· Adjustment-free VCO coil
· Low power dissipation (typ. 170 mW)
· S/N 65 dB or more
· Inter-modulation interference ratio: 50 dB or more
· AGC amp built in (Reduction range: 55 dB)
· Adjustment-free VCO coil
AN8946SB Typical Application
· BS/CS tuner, television
AN8946SB Connection Diagram
AN8946SB
PDF/DataSheet Download
- Datasheet: AN8946SB
- File Size: 89063 KB
- Manufacturer: PANASONIC [Panasonic Semiconductor]
- Click here to Download
